ViewSonic IFP5550 55″ 4K Interactive Display
Featuring 4K Ultra HD resolution and an advanced, next-generation touchscreen, the ViewSonic® ViewBoard™ IFP5550 delivers incredible collaborative capabilities for 21st century boardrooms and classrooms.

ENHANCED TOUCHSCREEN PERFORMANCE
View Sonic IFP550 interactive display delivers an ultra-smooth, natural handwriting experience. 20-point touch allows multiple users to simultaneously write or draw on the display’s surface using styluses or their fingers, or both at the same time. Dual-tip pen support allows users to simultaneously write or draw with two different colors.

IMMERSIVE STEREO SOUND
Designed with dual 10W stereo speakers and a 15W subwoofer, this display combines incredible room-filling sound with amazing screen performance for an immersive multimedia experience.

MYVIEWBOARD™ DIGITAL WHITEBOARDING SOLUTION
myViewBoard digital whiteboarding software combines enterprise-level security with cloud-based portability and annotation tools to enhance the way your team connects and collaborates.
VIEWBOARD CAST CONTENT SHARING SOFTWARE
ViewBoard Cast enables content streaming from mobile devices onto a ViewSonic display over wireless or cable networks. Multiple users can simultaneously share that content onto the ViewSonic display. Multi-screen casting allows up to nine client screens to be shown on the ViewSonic display. Popular platforms such as Windows, Mac, iOS-Airplay, Android, and Chrome are supported.

SMARTPORT USB™
The ViewSonic SmartPort USB function allows devices to be plugged into any video source on the display, while still providing simultaneous access to the display’s front-facing USB ports.

ULTRA HD RESOLUTION
With four-times the resolution of Full HD, this Ultra HD 3840×2160 display delivers a breathtaking viewing experience with immersive images that are vibrant, clear, and as large as life.
ANDROID OS
Android 7.0 provides enhanced graphics and an HTML engine for a better video and browsing experience.
ENERGY STAR CERTIFICATION
This is an ENERGY STAR certified product that can save on energy costs* while reducing greenhouse gases.
*Energy savings may vary based on actual usage and other factors.
DEDICATED CAMERA PORT
A dedicated camera port allows you to easily connect a conference camera to the display. This enables video conferencing and recording directly from the display, regardless of whether the display is connected to Android or PC.
VERSATILE CONNECTIVITY
An HDMI output, multiple HDMI inputs, and multiple USB ports deliver versatile connectivity to diversified storage devices, peripherals, and high-definition electronics for enhanced convenience and flexibility.
DISPLAY SIZE (IN.)
55
VIEWABLE AREA (IN.)
54.6
LIGHT SOURCE
LED
RESOLUTION
3840 x 2160
ASPECT RATIO
16:9
STATIC CONTRAST RATIO
1,200:1
BACKLIGHT LIFE (HOURS)
50,000
BRIGHTNESS
350 cd/m2
RESPONSE TIME (TYPICAL GTG)
8ms
VIEWING ANGLES
178º horizontal, 178º vertical
PANEL SURFACE
Anti-glare 7H tempered glass
NETWORKING
ETHERNET LAN
10/100/1000 Mbps
EMBEDDED PLAYER
OS
Embedded ViewBoard OS
GPU
ARM Mali450 Quad Core
CPU
ARM Dual Core Cortex A73
CPU PROCESSOR SPEED
1.2GHz
MEMORY
2GB
STORAGE
16GB
BUILT-IN SOFTWARE
myViewBoard, Chromium browser, Zoom, ViewBoard Cast
AUDIO
INTERNAL SPEAKERS
10W (x2)
SUBWOOFER
15W (x1)
CONNECTOR
HDMI 2.0 IN
3
HDMI OUT
1
VGA
1
COMPOSITE RCA
1
3.5MM AUDIO IN
1
3.5MM AUDIO OUT
1
SPDIF AUDIO OUT
1
USB 3.0
2
USB 2.0
4
SLOT-IN PC SLOT
1
USB B TOUCH PORT
2
RS232
1
ETHERNET LAN (RJ45)
1
WIFI MODULE SLOT
1
POWER
VOLTAGE
100-240 VAC
CONSUMPTION (MAX)
350W
CONSUMPTION (TYPICAL)
81W
STAND-BY
<0.5W
CONTROLS
ON SCREEN DISPLAY
Input, Volume, Backlight, Audio, Screen, Display, Adjust
REMOTE CONTROL
Volume, Channel, Source, Mute, Back, Input, Menu
OPERATING CONDITIONS
TEMPERATURE
32-104º F (0 – 40º C)
HUMIDITY (NON-CONDENSING)
10-90%
TOUCH
TOUCH TECHNOLOGY
Infrared
TOUCH POINTS
20-Point Touch
TIP DETECTION
Dual tips, 3mm and 8mm
WEIGHT (IMPERIAL)
NET (LBS)
68.3
GROSS (LBS)
86.0
WEIGHT (METRIC)
NET (KG)
31.0
GROSS (KG)
39.0
DIMENSIONS (IMPERIAL) (WXHXD)
PACKAGING (IN.)
56.2 x 34.6 x 8.7
PHYSICAL (IN.)
49.9 x 30.4 x 3.3
DIMENSIONS (METRIC) (WXHXD)
PACKAGING (MM)
1428.0 x 878.0 x 220.0
PHYSICAL (MM)
1268.0 x 773.0 x 85.0
MOUNT
VESA COMPATIBLE
400 x 200 mm
ADDITIONAL HARDWARE
CAMERA MOUNTING BRACKET
1
GENERAL
WARRANTY
3-year limited warranty on parts, labor and backlight, onsite warranty
RECYCLE/DISPOSAL
Please dispose of in accordance with local, state or federal laws.
PACKAGE CONTENTS
IFP5550 display, stylus pen x 2, power cable, HDMI cable, USB cable, AV cable, remote control with batteries, Camera plate, M8 screw x 8, Quick Start Guide
REGULATIONS
cTUVus, FCC, ENERGY STAR, Mexico Energy, CE, CB, RoHS, ErP, WEEE
DIMENSIONS
49.9 x 30.4 x 3.3 in / 1268.0 x 773.0 x 85.0 mm


- Menu Controls
- USB 2.0 x3
- VESA® Compatible Wall Mount 400 x 200 mm
- HDMI 2.0 In
- HDMI Out
- USB 2.0
- USB B Touch Port x2
- VGA In
- Audio In
- HDMI 2.0 In x2
- Camera Port
- USB 3.0
- Composite RCA Video In
- Audio Out
- Ethernet Lan (RJ45)
- RS232
- SPDIF
